Light Duty Lathe Machine



<< Previous   Light Duty Lathe Machine

Product Code : 06

Product Specification
                      LATHE MACHINE OUT STANDING DESIGN AND FEATURES

LATH BED:- THE LATH BED IS DESIGNED TO THE SPECIFICATIONS WHICH PROVIDES GREAT STRENGTH TO RESIST FORSANAL STRAINS.



HEAD STOCK:-  THE STRONGY CONSTITUTED HEAD STOCK IS OF FRICTIONAL AND STRAM LINED DESING.



CARRIGE:- THE CARRIGE HS LARGE BEARING SURFACE MINIMISIN THE CORCE PER UNIT BEARING AREA AND HENCE WEAR ON THE BED WAYS.



APPRON:- IT IS PROVIED WITH SAFELY INTER LOCK, WHICH PREVENTS SIMULTANEOUS ENGAGEMENTS OF FEED AND THREADING MACHANISM.



TAIL STOCK:- THE TAIL STOCK HAS LONG BEARIN ON DED ND DASE IS ADJUSTABLE FOR TAPER TUNING .



SPECIFICATION OF MACHINE

9  FEET  BED

LATH MACHINE

7 FEET  BED

LATH MACHINE

SPECIFICATION OF MACHINE

6 FEET  BED

LATH MACHINE

4.5  FEET  BED

LATH MACHINE

LENGTH OF BED

9’ (2745)

7’ (2134)

LENGTH OF BED

6’ (1828)

4’6’’(1370)

WIDTH OF BED

12.3/4 (323)

12.3/4 (323)

WIDTH OF BED

9.1/2” (241)

9. 1/2” (241)

HEIGHT OF CENTER

10” (254)

10” (254)

HEIGHT OF CENTER

6.1/2” (165)

6.1/2(165)

MAX.SWING OVER BED

20” (508)

20” (508)

ADMIN BETWEEN CENTER

47” (1194)

29” (725)

MAX.SWING OVER CARRIEGE

10”  (254)

10”  (254)

SWING OVER BED

13” (335)

13” (335)

ADMIN BETWEEN CENTER

62 ” (965)

38” (965)

SPINDLE BORE

1.5” (40)

1.5” (40)

LENGTH OF GAP

12” (305)

12” (305)

LEAD SCREW

.1” X 4 TPI

.1” X 4 TPI

SPINDLE BORE

2.1/8 ” (54)

2.1/8 ” (54)

THREDING RANGE MM.

M 1 TO M 6

M 1 TO M 6

SPINDLE NOSE

0.3” X 6 TPI

0.3” X 6 TPI

THREDING RANGE INCH

2 TPI  TO  24 TPI

2 TPI  TO  24 TPI

LEAD SCREW

1.5 ” X 4 TPI

1.5 ” X 4 TPI

NO OF SPINDLE SPEED

6

8

V-BELT

C-72

C-72

RANGE OF SPINDLE SPEED

40 TO 950 RPM

40 TO 950 RPM

NO OF SPINDLE SPEED

8

8

POWER OF REQUIRE

3‑PH 2 H.P

3‑PH 1 H.P

RANGE OF SPINDLE SPEED

25 TO 450 RPM

25 TO 450 RPM

WEIGHT NET/GROSS

600/800

425/575

POWER OF REQUIRE

3‑PH 2 H.P (1440 RPM)

3‑PH 2 H.P (1440 RPM)







WEIGHT NET/GROSS

1750 KG

1500 KG









WE RESERVE RIGHT TO ALTER ON MODIFIES DIMENSION AND DESIGN WITHOUT NOTICE.



STANDARD ACCESSORY:- CHUCK PLATE, CHANGE GEAR SET FOR INCH AND MM TRADE, TRADE DIAL INDICATOR , 2 DED CENTER, CENTER SLEVERS AND SPINDLE, SQUARE TOOLS POST & SPANNER.
